Add the following:
Loss on drying
(where it is labeled as Azithromycin monohydrate and has a
Watercontent of between 4.0%and 6.5%)(see
Thermal Analysis á891ñ)
[NOTEThe quantity taken for the determination may be adjusted,if necessary,for instrument sensitivity.
]Determine the percentage of volatile substances by thermogravimetric analysis in an appropriately calibrated instrument,using about 10mg of Azithromycin,accurately weighed.Heat the specimen at the rate of 10

per minute between ambient temperature and 150

in an atmosphere of nitrogen at a constant flow rate of about 35mLper minute.From the thermogram plot the derivatives of the loss on drying (percent loss per minute),identify the inflection points of the two weight loss steps at about 70

and 130

:it loses not more than 4.5%of its weight between ambient temperature and the inflection point at about 70

,and between 1.8%and 2.6%between the inflection point at about 70

and the inflection point at about 130

.
USP28
Limit of related substances
[NOTEUse water that has a resistivity of not less than 18Mohm-cm.
]
Mobile phase
Proceed as directed in theAssay.
pH7.5Potassium phosphate buffer
Transfer 2.7g of monobasic potassium phosphate to a 1000-mLvolumetric flask.Dilute with water to volume,and mix.Adjust with 10Npotassium hydroxide to a pHof 7.5±0.1.
Dilution solution
Prepare a mixture ofpH7.5Potassium phosphate buffer and acetonitrile (750:250).
Standard stock solution
Quantitatively dissolve accurately weighed quantities of USP Desosaminylazithromycin RS,USP
N-Demethylazithromycin RS,and
USP Azithromycin RSwith acetonitrile to obtain a solution having known concentrations of about 45,105,and 160µg per mL,respectively.
Standard solution
Transfer 4.0mLof
Standard stock solution to a 200-mLvolumetric flask,dilute with
Dilution solution to volume,and mix.This solution contains known concentrations of USP Desosaminylazithromycin RS,USP
N-Demethylazithromycin RS,and
USP Azithromycin RSof about 0.9,2.1,and 3.2µg per mL,respectively.
Test solution
Transfer about 33mg of Azithromycin,accurately weighed,to a 100-mLvolumetric flask,add 5mLof acetonitrile,and sonicate for about 20seconds to dissolve.Dilute withDilution solution to volume,and mix.[NOTEUse this solution within 6hours.]
Chromatographic system(see Chromatography á621ñ)
The liquid chromatograph is equipped with an amperometric electrochemical detector with dual glassy carbon electrodes operated in the oxidative screen mode with electrode 1set at +0.70±0.05Vand electrode 2set at +0.85±0.05V,and the background current optimized to 95±25nanoamperes,a 4.6-mm ×5-cm guard column that contains 5-µm packing L29,and a 4.6-mm ×15-cm analytical column that contains 5-µm packing L29or 3-µm packing L49without the guard column.
[NOTEIn general,maintain electrode 1at 0.12Vless than electrode 2,and maintain the electrodes at a constant temperature of about 26

.
]The flow rate is about 0.4mLper minute.Chromatograph the
Standard solution,and record the peak responses as directed for
Procedure:the relative retention times are about 0.38for desosaminylazithromycin,0.54for
N-demethylazithromycin,and 1.0for azithromycin;the column efficiency is not less than 1500theoretical plates for the azithromycin peak;the tailing factor for each of these compounds is not more than 1.5;and the relative standard deviation for replicate injections is not more than 5%for each of these compounds.
Procedure
Separately inject equal volumes (about 50µL)of the
Standard solution and the
Test solution into the chromatograph,record the chromatograms,using an elution period for the
Test solution that is 3.3times the elution time of the azithromycin peak in the chromatogram of the
Standard solution,and measure the areas for all of the peaks.Calculate the percentages of desosaminylazithromycin and
N-demethylazithromycin in the Azithromycin taken by the formula:
0.1(CP/W)(ri/rS),
in which
Cis the concentration,in µg per mL,of the appropriate USP Reference Standard in the
Standard solution;Pis the designated potency,in percentage,of the relevant USP Reference Standard;
Wis the weight,in mg,of Azithromycin taken to prepare the
Test solution;and
riand
rSare the peak area responses for the relevant analyte in the chromatograms obtained from the
Test solution and the
Standard solution,respectively.Calculate the percentages of other related substances in the Azithromycin taken by the formula:
0.01(CP/W)(ri/rS),
in which
Cis the concentration,in µg per mL,of
USP Azithromycin RSin the
Standard solution;Pis the designated purity,in µg per mg,of
USP Azithromycin RS;
Wis the weight,in mg,of Azithromycin taken to prepare the
Test solution;riis the peak area response for an individual related substance peak in the chromatogram obtained from the
Test solution;and
rSis the peak area response for the azithromycin peak in the chromatogram obtained from the
Standard solution.Not more than 0.3%of desosaminylazithromycin,0.7%of
N-demethylazithromycin,and 1.0%of any other individual related substance is found;and the sum of all related substances is not more than 3.0%.
Assay
[NOTEUse water that has a resistivity of not less than 18Mohm-cm.
]
Mobile phase
Dissolve 5.8g of monobasic potassium phosphate in 2130mLof water,add 870mLof acetonitrile,and mix.Adjust with about 6mLof 10Npotassium hydroxide to a pHof 11.0±0.1,and pass through a filter having a 0.5-µm or finer porosity,and degas.Make adjustments if necessary (see
System Suitabilityunder
Chromatography á621ñ).
Standard stock preparation
Transfer about 16.5mg of
USP Azithromycin RS,accurately weighed,to a 100-mLvolumetric flask,add 10mLof acetonitrile,and dissolve by swirling and with the aid of brief sonication.Dilute with acetonitrile to volume,and mix.
Standard preparation
Transfer 2.0mLof the
Standard stock preparation to a 100-mLvolumetric flask,dilute with
Mobile phaseto volume,and mix to obtain a
Standard preparationhaving a known concentration of about 0.0033mg of
USP Azithromycin RSper mL.
Assay preparation
Transfer about 16.5mg of Azithromycin,accurately weighed,to a 100-mLvolumetric flask,add 10mLof acetonitrile,and dissolve by swirling and with the aid of brief sonication.Dilute with acetonitrile to volume,and mix.Transfer 2.0mLof the solution so obtained to a 100-mLvolumetric flask,dilute withMobile phaseto volume,and mix.
Resolution solution
Transfer about 8mg of
USP Azaerythromycin A RSto a 50-mLvolumetric flask,add 5mLof acetonitrile,and dissolve by swirling and with the aid of brief sonication.Dilute with
Mobile phaseto volume,and mix.Transfer 2.0mLof the solution so obtained and 2.0mLof the
Standard stock preparation to a 100-mLvolumetric flask,dilute with
Mobile phaseto volume,and mix.
Chromatographic system(see Chromatography á621ñ)
The liquid chromatograph is equipped with an amperometric electrochemical detector with dual glassy carbon electrodes operated in the oxidative screen mode with electrode 1set at +0.70±0.05Vand electrode 2set at +0.82±0.05V,and the background current optimized to 85±15nanoamperes,a 4.6-mm ×5-cm guard column that contains 5-µm packing L29and a 4.6-mm ×15-cm analytical column that contains 5-µm packing L29or 3-µm packing L49without the guard column.The flow rate is about 1.5mLper minute.Chromatograph the
Resolution solution,and record the responses as directed for
Procedure:the relative retention times are about 0.7for azaerythromycin Aand 1.0for azithromycin with the L29column and about 0.8for azaerythromycin Aand 1.0for azithromycin with the L49column;and the resolution,
R,between azaerythromycin Aand azithromycin is not less than 2.5.Chromatograph the
Standard preparation,and record the responses as directed for
Procedure:the tailing factor for the azithromycin peak is not less than 0.9and not more than 1.5;the column efficiency is not less than 1000theoretical plates;and the relative standard deviation for replicate injections is not more than 2.0%.
Procedure
Separately inject equal volumes (about 50µL)of the
Standard preparationand the
Assay preparationinto the chromatograph,record the chromatograms,and measure the areas for the major peaks.Calculate the quantity,in µg,of azithromycin (C
38H
72N
2O
12)in each mg of Azithromycin taken by the formula:
(WP/w)(rU/rS),
in which
Wis the quantity,in mg,of
USP Azithromycin RStaken to prepare the
Standard preparation;Pis the potency,in µg of azithromycin per mg,of
USP Azithromycin RS;
w is the quantity,in mg,of Azithromycin taken to prepare the
Assay preparation;and
rUand
rSare the azithromycin peak responses obtained from the
Assay preparationand the
Standard preparation,respectively.
