C
15H
10I
4NNaO
4·
xH
2O(anhydrous)
798.85
L-Tyrosine,O-(4-hydroxy-3,5-diiodophenyl)-3,5-diiodo-,monosodium salt,hydrate.
Monosodium L-thyroxine hydrate
[25416-65-3].
Anhydrous
[55-03-8].
Packaging and storage
Preserve in tight containers,protected from light.
Identification
A:
Ignite about 50mg in a platinum dish over a flame:it decomposes and liberates iodine vapors.
B:
To about 0.5mg add 7.5mLof acid sodium chloride solution (prepared by mixing 300mLof water,250mLof alcohol,100mLof 1Nsodium hydroxide,and 100mLof hydrochloric acid)and 1mLof sodium nitrite solution (1in 100).Allow to stand in the dark for 20minutes,and add 1.25mLof ammonium hydroxide:a pink color is produced.
Specific rotation á781Sñ:
between
-5

and
-6

.
Test solution:
an amount equivalent to 30mg of anhydrous Levothyroxine Sodium per mL,in a mixture of alcohol and 1Nsodium hydroxide (2:1).
Water,Method IIIá921ñ
Dry about 500mg,accurately weighed,over phosphorus pentoxide at 60

and at a pressure not exceeding 10mm of mercury for 4hours:it loses not more than 11.0%of its weight.
Limit of inorganic iodides
Extracting solution
Prepare a 1in 100solution of sulfuric acid in water.
Reference solution
Dissolve an accurately weighed quantity of potassium iodide in water to obtain a stock solution containing 0.131mg,equivalent to 0.100mg of iodide per mL.Transfer 0.6mLof this stock solution into a 1000-mLvolumetric flask,dilute with the Extracting solutionto volume,and mix.Each mLof the Reference solutioncontains 0.06µg of iodide.[NOTEPrepare this solution on the day of use.]
Test solution
Transfer 7.5mg of Levothyroxine Sodium to a beaker,add 100mLof the Extracting solution,and sonicate for 5minutes.
Electrode system
Use an iodide-specific,ion-indicating electrode and a silver-silver chloride reference electrode connected to a pHmeter capable of measuring potentials with a minimum reproducibility of ±1mV(see
pHá791ñ).
Procedure
Transfer the Reference solutionto a beaker containing a magnetic stirring bar.Rinse and dry the electrodes,insert in the solution,stir for 5minutes or until the reading stabilizes,and read the potential,in mV.Repeat this process using the Test solution.The requirements of the test are met if the Test solutionhas a higher potential,in mV,than the Reference solution:the limit is 0.08%.
Limit of liothyronine sodium
Mobile phase,and Chromatographic system
Proceed as directed in the
Assay.
Standard solution
Prepare as directed for Standard preparation in the Assay.
Test solution
Proceed as directed for the Assay preparation.
Procedure
Proceed as directed in the
Assay.Calculate the quantity,in µg,of liothyronine sodium (C
15H
11I
3NNaO
4)in the sample taken by the formula:
(672.96/650.98)(10C)(rU/rS),
in which 672.96and 650.98are the molecular weights of liothyronine sodium and liothyronine,respectively,
Cis the concentration,in µg per mL,of
USP Liothyronine RSin the
Standard preparation,and
rUand
rSare the liothyronine peak responses obtained from the
Test solutionand the
Standard solution,respectively:not more than 2.0%of liothyronine is found.
Assay
Mobile phase
Prepare a degassed and filtered mixture of water and acetonitrile (60:40)that contains 0.5mLof phosphoric acid in each 1000mL.Make adjustments if necessary (see
System Suitabilityunder
Chromatography á621ñ).
Standard preparation
Transfer accurately weighed quantities of
USP Levothyroxine RSand
USP Liothyronine RSto a suitable container,dissolve in and dilute quantitatively and stepwise with
Mobile phaseto obtain a solution having known concentrations of about 10µg of levothyroxine per mLand 0.2µg of liothyronine per mL.
Assay preparation
Transfer an accurately weighed portion of about 100µg of Levothyroxine Sodium into a centrifuge tube,add 2glass beads,pipet 10mLof Mobile phaseinto the tube,and mix using a vortex mixer for 3minutes.Centrifuge to obtain a clear supernatant,filtering if necessary.
Chromatographic system
(see
Chromatography á621ñ)The liquid chromatograph is equipped with a 225-nm detector and a 4.6-mm ×25-cm column that contains packing L10.The flow rate is about 1.5mLper minute.Chromatograph the
Standard preparation,and record the peak responses as directed for
Procedure:the resolution,
R,between the liothyronine and levothyroxine peaks is not less than 5.0,and the relative standard deviation for replicate injections is not more than 2.0%for levothyroxine.
Procedure
Separately inject equal volumes (about 100µL)of the
Standard preparationand the
Assay preparationinto the chromatograph,record the chromatograms,and measure the responses for the major peaks.Calculate the quantity,in µg,of C
15H
10I
4NNaO
4in the portion of Levothyroxine Sodium taken by the formula:
(798.85/776.87)(10C)(rU/rS),
in which 798.85and 776.87are the molecular weights of levothyroxine sodium and levothyroxine,respectively,
Cis the concentration,in µg per mL,of
USP Levothyroxine RSin the
Standard preparation,and
rUand
rSare the levothyroxine peak responses obtained from the
Assay preparationand the
Standard preparation,respectively.
